dye M3s - EXPLODED VIEW; PARTS LIST

26
WWW.DYEPAINTBALL.COM
1 Lockdwn2 feed neck
2 Ball Detent Clip
3 Eye Pipe
4 Eye Seal
5 M3s Body
6 FL-21™ Bolt
7 Tool-less Back Cap
8 ULs Barrel Tip
9 UL Barrel Back
10 Solenoid
11 Sensor Board
12 Eye Wire
13 Hyper6s Pro™
14 Front Frame Mounting Screw
15 Rear Frame Mounting Screw
16 Ultralite Frame
17 Main Circuit Board
18 ShiftPort ASA
19 Sticky Grip
20 Transfer Board
21 Reach Trigger
22 Front Grip Sleeve
PARTS LIST
1
2
4
3
5
6
8
7
9
12
11
10
14
15
16
17
19
18
21
20
22
EXPLODED VIEW
13
