Replacement Parts List
For replacement parts, call our customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m.,
CST, Monday – Friday.
PART DESCRIPTION PART #
1 Badge 102-22006
2 Lid handle assembly 70-02-627
3 Heat shield assembly 70-02-628
4 Lid bumper 70-02-629
5 Cooking grate 70-02-630
6 Charcoal grate 70-02-631
7 Side table 70-02-632
8 Rear support, side table 70-02-633
9 Front support, side table 70-02-634
10 Lid damper 70-02-635
11 Lid assembly 70-02-636
12 Lid hinge 70-02-637
13 Cooking grate bracket 70-02-638
14 Lid hinge pin with cotter pin 70-02-639
15 Firebox hinge 70-02-640
16 Firebox assembly 70-02-641
17 Firebox damper 70-02-642
18 Left support, rebox 70-02-643
19 Right support, rebox 70-02-644
20 Left leg bracket 70-02-645
21 Leg bumper 70-02-646
22 Leg latch 70-02-647
23 Left leg assembly 70-02-648
24 Leg cap 70-02-649
25 Leg axle 70-02-650
26 Right leg assembly 70-02-651
27 Wheel 70-05-104
28 Axle 70-02-653
n/a Hardware pack 70-09-565
