REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, 8:30 a.m. – 4:30 p.m.,
CST, Monday – Friday.
PART DESCRIPTION PART #
Lid assembly
Temp gage assembly
Badge
M6 screw with cap-specially secure lid pivot pin
Lid pivot pin
Grease pan assembly
Firebox assembly - includes lid bumpers
Grease cup assembly
Door Magnet
Side table-right
Support for right side table
Side table front panel assembly-right
Right support for upper front door brace
Upper front door brace
Support for door pin
Left support for upper front door brace
Side table front panel -left
Left side burner assembly
Side burner cooking grate
Control knob
Control knob bezel
Door handle sleeve
Door handle bezel
Door handle
Door assembly-right
Door assembly-left
Ignition wire -side burner
Side burner with venture tube-includes screw to attach.
Ignition electrode assembly -side burner
Support for left side burner table
Side burner soup plate
Side burner cover
Heat tent
AA battery (1.5V)
Cooking grate
Warming rack
Lid handle
Lid handle bezel
Control panel assembly
Bottom shelf
Non-locking swivel caster (3”) - Includes 4 screws/at washers/spring washers
Locking swivel caster (3”)- Includes 4 screws/at washers/spring washers
Cart side panel-right
Side burner valve and hose assembly
166 - 02001
104 - 12005
104 - 22006
104 - 12001
104 - 12002
106 - 04013
166 - 03001
104 - 04014
104 - 14020
105 - 04001
105 - 04003
105 - 14001
166 - 14002
166 - 04011
105 - 14024
105 - 14025
105 - 44001
105 - 44002
105 - 44003
104 - 13010
104 - 13009
104 - 14023
104 - 14022
104 - 14021
166 - 04020
166 - 44020
105 - 44004
105 - 44005
105 - 44006
105 - 44007
105 - 44008
105 - 44009
105 - 13003
104 - 05002
166 - 13002
166 - 13001
106 - 12003
105 - 12004
106 - 13008
166 - 04006
105 - 04017
105 - 04019
105 - 04010
105 -13016
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
