ASSEMBLY INSTRUCTIONS
4
4. Load Cylinder Housing (D) onto Post (E).
Slide Cylinder housing (D) down.
5. Unscrew ignitor knob (marked with lighting bolt) from the
control panel on the head assembly (C). Insert AAA
battery (MM) with positive end (+) outward. Replace ignitor
knob.
D
E
WARNING
The electronic ignition requires 1 āAAAā alkaline battery, which is included.
DO NOT mix old and new batteries.
DO NOT mix alkaline, standard (Carbon-Zinc), or rechargable (Nickel-Cadmium) batteries.
DO NOT dispose of batteries in fire. Improper disposal may cause batteries to leak or explode.
Hardware Used
MM
x 1
AAA battery
MM
C
5
