Page 960707-122
9160-00
RECEPTACLE
PANEL
REF# Part Number QTY Description
1 57030-009 1 Circuit Breaker 25A/240V
2 91286-001 2 Circuit Breaker 20A/120V
3 97360-000 1 Receptacle Nema L14-30R
4 50766-000 1 Duplex Receptacle Nema 5-20R
5 48042-001 1 Ground Lug
6 16346-014 1 End Cover
REF# Part Number QTY Description
12 15482-000 1 Gas Cap
13 16346-006 1 Complete Generator Assembly
14 15632-007 1 Engine B/S Intek (1)
210317-0191-B1
14 15632-008 1 Engine B/S Intek (2)
210312-0190-B1
15 468-000 2 Cap Screw 5/16-18 X 1.5
16 480-000 2 Lockwarsher 5/16
17 466-000 2 Cap Screw 1/4-20 X .75
18 512-000 2 1/4 Flat Washer
19 16133-000 2 Leather Washer
20 81018-008 1 Clamp
21 98771-000 1 Fuel Valve
22 62999-001 2 Fuel Line Clamp
23 40078-000 28" 1/4" Fuel Line
24 64024-000 1 Fuel Tank 4.5 Gal.
25 15462-029 1 Fuel Tank Tray
NI 16237-003 1 Muffler Spark Arrestor
(1) Model DL6000IE only
(2) Model DL6000I only
To Next Page
