1. Connect the power cord to the AC adaptor.
Figure 2-3 Connecting the power cord to the AC adaptor (2-pin plug)
Figure 2-4 Connecting the power cord to the AC adaptor (3-pin plug)
Either a 2-pin or 3-pin adaptor/cord is included with the computer
depending on the model.
2. Plug the power cord into a live wall outlet.
3. Connect the DC output plug of the AC adaptor to the Thunderbolt™ 4/
USB Type-C™ port on your computer. The DC IN/Battery indicator
glows.
You can also establish connection through the USB Type-C™ adapter
(provided with some models). Refer to the USB Type-C™ Adapters
section for more information.
Figure 2-5 Connecting the DC output plug to the computer
1. Thunderbolt™ 4/USB Type-C™
port
2. DC output plug
Product appearance depends on the model you purchased.
User's Manual
2-7
