L OUDSPEAKERS
41
The F9CWH is an extremely powerful and yet compact Mid/Hi-
cabinet that has been designed for medium and long-throw
applications. The Constant Directivity horn HT94 is coaxially aligned
in a conical mid-frequency horn and offers a nominal radiation angle
of 90° x 40°, which provides extremely smooth transmission without
distressing interference in the x-over frequency range between the
mid and high-frequency horns.
The mid-frequency range is reproduced by an Electro-Voice DL 12ST
speaker system, while high frequency reproduction is taken care of
by an Electro-Voice DH2T driver with titanium diaphragm, which is
renowned for his excellent vocal definition and crystal-clear treble
sound. The SPL of 105dB/1W/1m allows almost doubling the
throw-capability of conventional direct-radiating loudspeaker cabi-
nets.
Employing at least two Lo-cabinets per side – e.g. two F5 or two
F118 – for bass sound reproduction is recommended to match bass-
SPL to the exceptionally high efficiency of the F9CWH.
(also refer to “Xa5-System” in the Application Guide on page 54).
F9
F120
By designing its 2-way speaker system F120, DYNACORD set a new
standard for professional 12" 2-way cabinets. A sound pressure level
of 100 dB, wide coverage and its excellent sound quality make the
F120 equally suitable to be used as full-range cabinet or as Mid-Hi
component in active 2-way applications. When comparing the F120
to conventional 12" 2-way speaker systems, it provides nearly
double the throw and power as well as a convincingly natural
reproduction of vocals. An Electro-Voice DL12 ST 12" speaker serves
a s woofer system while an Electro-Voice DH2T driver with titanium
diaphragm and HT94 Constant Directivity horn provides
exceptionally powerful mid-range sound and crystal-clear trebles.
The newly designed frequency x-over is furnished with halogen
lamps and thermal-breakers, which provide reliable protection
against overload. The system-switch on the connection board allows
easily configuring the F120 for full-range operation or connection to
DYNACORD system power amps like the PM 2600 or Xa2600. The
carrying handles are prepared for retrofitting a TÜV-approved
rigging-kit to allow trouble-free “flying” applications.
