DynaGen Tough Series User Manual

Introduction
5
© 2019 DynaGen Technologies Inc
TOUGH Series Manual
Specification
Rating
Thermal Shock and Cycling
SAE1455
Vibration Profiles
SAE1455
Electric Static Discharge
SAE1113-13: +/-8KV Direct Discharge, +/-15kV Air gap discharge
UL
UL 6200 recognized component. Consult factory for UL conditions of
acceptability.
Physical Specifications
Specification
Rating
Operating Temperature
-40 to +158°F (-40 to +70°C)
LCD Viewing Temperature
-4 to +158°F (-20 to +70°C )
(Optional heater available, call factory)
Weight
Weight w/ RelayPak
0.83lb (0.38kg)
1.32lb (0.60kg)
Dimensions - controller (no gasket)
- controller w/ gasket
- controller w/ gasket and RelayPak
4.17" x 6.50" x 1.38" (10.59cm x 16.51cm x 3.51cm)
4.41" x 6.79" x 1.38" (11.20cm x 17.25cm x 3.51cm)
4.41" x 6.79" x 3.33" (11.20cm x 17.25cm x 8.46cm)
Electrical Specifications
Specification
Rating
Operating Voltage
5.5 ~ 36 VDC
Standby Current (Minimum)
Auto Mode: 60mA @ 12VDC, 38mA @ 24VDC (back lighting off)
Off Mode: 80mA @ 12VDC, 45mA @ 24VDC (back lighting off)
Actual consumption could be more depending on connected sensors and other
I/O.
Switched Inputs
+Battery, Ground, Open, Closed
Switched Outputs
+Battery @ 1A Max
Low Resistance Sensors
0 ~ 750Ohm
High Resistance Sensors
0 ~ 7,500Ohm
Universal Sensors
0 ~ 750Ohm, 0 ~ 7,500Ohm, 0 ~ 5 VDC, 4 ~ 20mA
Magnetic Pickup
10 ~ 10,000Hz at 1 ~ 50 VAC
AC Voltage (Line-To-Line)
UL Approved Range: 50 ~ 600 VAC True RMS, Accuracy: 2% Full Scale.
Non - UL Range: 50 ~ 670 VAC
Do not connect more than 600VAC to the controller for UL approved installations
or 700VAC for locations where UL is not required.
Communications
SAE J1939 (Tier II, III, IV)
External Sensor Power
TG410 only: 5 VDC at a max load of 200mA
