DynaGen Tough Series User Manual

Installation
8
© 2019 DynaGen Technologies Inc
TOUGH Series Manual
Terminal
Name
Description
J3-2
Switched Input E
Configurable to detect +Battery, Ground, or Open
J3-3
Switched Output D
Outputs +Battery voltage when active (Max Current: 1A)
J3-4
Switched Output E
Outputs +Battery voltage when active (Max Current: 1A)
J3-5
Switched Output F
Outputs +Battery voltage when active (Max Current: 1A)
J3-6
No Connection
No Connection
J3-7
Sensor Ground
Provides ground return for 2-wire sensors
J3-8
Sensor Input D
Universal sensor input (0 - 750Ohm, 0 - 7,500Ohm, 0 - 5 VDC, 4 - 20mA) See
Universal Sensor section for more information.
