troubleshooting
8 DBC410 Installation Manual Rev K.docx
Check the following list. If you are still unable to rectify the situation, contact your nearest Dynalite office. A
complete list of distributors worldwide can be found on the Internet at: www.philips.com/dynalite
Please ensure that you have completed the following prior to calling our technical support department.
 Check all symptoms in the Troubleshooting list
 Check for any deviations between the installation and the installation instructions
 Make a list of the model numbers of all devices used in the system
SYMPTOM
PROBABLE CAUSE
ACTION
Dimmer does not operate at all. No Service LED
activity. Power supply indicator LED on PCB not lit.
Incorrect connection of Mains supply, or no
power available.
Check power supply to dimmer. Check Line and
Neutral input connections.
Power supply indicator LED lit, but no Service LED
activity.
Supply voltage too low, short circuit on
network. Control PCB faulty.
Check supply voltage is at least 75% of rated
voltage. Check 5V & 12V terminal voltages, 5V
supply must be present. Disconnect network bus
and restore power. Replace control PCB.
Dimmer will not respond to control panel push
buttons.
Control panel incorrectly wired or incorrect
configuration.
Check operation of LEDs on control panel. Push
button on panel and study response of service
LED.
Dimmer operates properly but circuit breakers keep
tripping.
Instant tripping: - short circuit on load.
Delayed tripping: - Dimmer overloaded.
Check load wiring for short circuits.
Verify dimmer loading with current tester (don’t
forget to de-rate for low power-factor loads and
transformer losses). Check that the breaker
terminals are tight.
Fluorescent lights won’t dim.
Wrong type of ballast or ballast incorrectly
wired. Control cable from DBC410 to ballasts
not installed.
Check ballast type. Check actual wiring against
ballast manufacturer’s diagram. Check 1-10V/DSI
cable and settings.
specification
Supply:
230V ±14% 50/60Hz Single Phase at 40A
Outputs:
4 x switched outputs at 10A
4 x signal control outputs, selectable to 1-10VDC and DSI
Optional Maintained Output:
1 x Maintained NC output for testing battery packs in fixtures (fed from MCB A, total load
maintained output & Ch 1 is 10A)
Protection:
4 x 10A single pole thermal magnetic circuit breakers
Switching Device:
Relay 12A nom. (resistive) 120A surge
Control Inputs:
1 x RS485 DyNet serial port
1 x programmable dry contact AUX input
User Controls:
Service Switch
Diagnostic LED
Internal Controls:
Programmable Logic Controller
Dynalite Accessory Module enabled
DyNet DC Supply +VE:
90mA (supply for approx. 4 Smart Panels)
Preset Scenes:
170
Supply Terminals:
Line, Neutral – 2 x 4mm
2
max conductor size
Output Terminals:
Line, Neutral for each channels 1-8
2 x 4mm
2
max conductor size
Earth link bar provided
0V/DSI , +V/DSI for each channel
1 x 2.5mm
2
max conductor size
Cable Entries:
Mains – 1 x 75mm x 53mm removable gland plate
Data – 1 x 25mm dia. knockout
Diagnostic Functions:
Device Online/Offline status
Circuit breaker trip reporting (optional)
Circuit run time tracking (optional)
Compliance:
CE, C-Tick
Construction:
Alloy/Steel wall mount case with epoxy finish
Dimensions:
Height 320mm x Width 225mm x Depth 75mm (excludes wall brackets)
Weight:
4.0 Kilograms
