6
18
Insert the direction pushrod into the hold of
quick-controller and tighten clamp connectors.
Apply the foam glue on the joiner of the
left and right wings.
Connector the aileron servos with
Y wires.
Fix the wing struts with PA 2.5*8mm
screw
Put the battery in position.
Fix the wing on fuselage with PA
2.3*20mm screw.
Installing the Battery position.
Apply the foam glue on the antenna and
insert it in the main wing as shown.
Glue left and right main wings together.
19 20
(Remark: The servo should be in center position)
