13
103 Pin, Lock, 10mm 1 138 Camshaft 1 173 Control ASSY 1
104 Washer, 8.2*170.8 1 139 Valve lifter 2 174 Governor Spring 1
105 Flange Nut M10 1 140 Intake Valve 1 175 Spring, Throttle return 1
106 O-ring, 14mm 1 141 Exhaust Valve 1 176 Governor Arm 1
107 Switch ASSY, Oil level 1 142 Seat, Valve spring 1 177 Governor Rod 1
108 Balancer 1 143 Retainer, EX. Valve spring 1 178 Bolt, Governor arm 1
109 Crankshaft 1 144 Rotator, Valve 1 179 Fuse 1
110 Radial Ball Bearing (6207) 2 145 Retainer, In. Valve spring 1 180 Battery Wire, Anode 1
111 Pin, Dowel 12*20 2 146 Valve Spring 2 181 Battery Wire, Cathode 1
112 Gasket, Cylinder head 1 147 Push Rod 2 182 Battery Cover 1
113 Bolt Head, 8*106 2 148 Exhaust Piper 1 183 Battery 1
114 Packing, Air cleaner 2 149 Cover COMP, Head 1 184 Brush ASSY 1
115 Stay ASSY, Manual choke 1 150 Washer COMP, Head cover 1 185 Pipe thread clamp 4
116 Grommet Fender 1 151 Bolt, Head cover 1 186 intake-tube 1
117 Carburetor ASSY 1 152 Nut M8 2 187 Gas valve 1
118 Packing, Carburetor 1 153 Pipe COMP EX. 1 188 pressure pipe，circlip 2
119 Heat Isolator, Carburetor 1 154 Gasket (B) EX. Pipe 1 189 pressure pipe 1
120 Flange Nut M6 4 155 Plate, Push rod guide 1 190 exit pipe 1
121 Stay, Air cleaner 1 156 Bolt, Pivot 2
