EXPLODED VIEW AND PARTS LIST
1 Gasoline Engine, Whole set 1 28 Supporting Stand 1 55 Flange Bolt M8*32 2
2 Frame COMP 1 29 Bolt M10*1.25*265 1 56 Muffler Stay 1
3 Bottom Rubber A 2 30 Plain washer 10 1 57 Muffler 1
4 Bottom Rubber B 2 31 Bearing 6207-2RS 1 58 Muffler Protector, Inner 1
5 Flange Nut M8 12 32 Rotator COMP 1 59 Flange Bolt M8*16 4
6 Flange Nut M6 4 33 Stator & Rotator ASSY 1 60 Seal, Muffler protector 1
7 Cushion, Frame 4 34 Generator Fan 1 61 Muffler Stay COMP 1
8 Bolt M6*12 4 35 Stator Cover 1 62 Side Muffler Protector 1
9 Rubber Pad, Frame 2 36 Stator ASSY 1 63 Control Panel Case 1
10 Handles 2 37 Stripe, Fuel tank 1 64 DC Output Post 2
11 Earth Terminal Set 1 38 Fuel Tank 1 65 Wheel ASSY 1
12 Flange Bolt M6*12 8 39 Fuel Filter 1 66 Pin 2
13 Receptacle 1 40 Packing Ring 1 67 Washer 20 2
14 Receptacle 1 41 Fuel Filler Cap COMP 1 68 Wheel COMP 2
15 Voltage Regulator 1 42 Fuel Sensor 1 69 Bracket 2
16 Circuit Breaker 1 43 Screw M5*1 2 70 Well Shaft 1
17 Control Panel 1 44 Gasket, Fuel tank 1 71 Recoil COMP 1
18 Voltmeter 1 45 Flange Bolt M6*22 4 72 Flange Bolt M6*8 3
19 Diode ASSY 2 46 Washer 4 73 Fan, Cover COMP 1
20 1 47 Collar 4 74 Flange Bolt M6*12 13
21 Boot, Engine switch 1 48 Cushion 4 75 Shroud COMP 1
22 Boot, Main wire harness 1 49 Outlet pipe 4.5*165 1 76 Clip, Oil blocker 3
23 Boot, AC output wire 1 50 Tube Clip 2 77 Grommet Drain Hole 1
24 Wire Harness ASSY 1 51 Rubber, Fuel tube 1 78 Start Motor 1
25 Flange Bolt M5*12 2 52 Fuel Cock 1 79 Flange Bolt M8*35 2
26 Alternator Cover 1 53 Muffler Protector 1 80 Flange Nut M16 1
27 Flange Bolt M6*175 4 54 Flange Bolt M6*14 4 81 Starting Pulley 1
82 Cooling Fan 1 122 Case COMP, Air cleaner 1 157 Arm, Valve rocker 2
83 Key 1 123 Separator, Air cleaner 1 158 Nut, Valve rocker arm 2
84 Flywheel COMP 1 124 Flange Nut M5 6 159 Nut, Pivot adjusting 2
85 Oil Seal, 35*52*8 2 125 Cover COMP, Air cleaner 1 160 Flange Bolt M8*40 7
86 Crank Case ASSY 1 126 Clip, Air Cleaner ware 2 161 Crankcase Cover 1
87 Oil blocker 1 127 Element, Air cleaner 1 162 Flange Bolt M5*10 3
88 Bolt, Drain plug 2 128 Seal, Air cleaner 1 163 Fan Cover 1
89 Washer, Drain plug 2 129 Packing, Heat isolator 1 164 Cap ASSY, Oil filler 1
90 Clip, Wire 1 130 Clip, Tube 4 165 Governor Kit 1
91 Flange Bolt M6*25 2 131 Valve, Dashpot check ASSY 1 166 Packing, Case cover 1
97 Cord Stop Switch 1 132 Tube, Fuel 45*165 1 167 Pin, Dowel 8*12 2
98 Grommet Cord 1 133 Tube, Breather 1 168 Piston Ring Set 1
99 Coil ASSY, Ignition 1 134 Flange Bolt M10*80 4 169 Clip, Piston pin 2
100 Oil Seal, 8*14*5 1 135 Head COMP, Cylinder 1 170 Piston 1
101 Radial Ball Bearing (6202) 2 136 Bolt head, M8*34 2 171 Pin, Piston 1
102 Shaft, Governor arm 1 137 Spark Plug 1 172 Connecting Rod ASSY 1
