Dynatron 900+ - Assembly and Maintenance

Dynatron 900
+™
16
SECTION VI
ASSEMBLY AND MAINTENANCE
PULLEY HEAD
Whenever the Pulley Head is replaced or removed from the device, turn the pulley head to the left
until the breach points are aligned and the pulley easily slips from the enclosure. Do not force.
REMOVING THE CHASSIS
1. Remove the two screws from the back panel of the chassis (A).
2. Remove the bottom plate and side panels will fall free.
