DWA-3000B-DO ANALYZER
8
CALIBRATION
제로 교정
Zero 000.0m g/L CAL
Span 08.11m g/L CAL
CALIBRATION
스판 교정
Zero 000.0m g/L CAL
Span 08.11m g/L CAL
CALIBRATION
스판 교정
Zero 000.0m g/L CAL
S p a n 0 8 .1 1 m g /L C A L
ZERO Calibration
Press to execute calibration by positioning the cursor on CAL as shown on above figure.
(Press key to stop & cancel the calibration)
4) SPAN Calibration
Move to below screen after completing ZERO Calibration.
SPAN calibration value according to the temperature is set up automatically and possible to
correct.
SPAN Calibration
Press keys to move the cursor position & enter values with keys.
SPAN Calibration
Press to execute calibration by positioning the cursor on CAL as shown on above figure
once the calibration value input is completed
(Press key to stop & cancel the calibration)
ENTER
ESC
CAL
ENTER
ESC
