Dyson DC26 Helpline Manual

helpline manual
19
Turbine head brush bar not operating
The brush bar will stop rotating if it becomes obstructed. The brush bar will operate immediately, once the obstruction is cleared.
Press the release catch and remove the
turbine head.
Ask the customer to check the suction
on the end of the wand handle. If
weak go to section 4 on p.16, if strong
continue with these checks.
Undo end cap with a coin. Pull the brush bar out from the turbine
head.
Using scissors, if necessary, carefully
cut away any hair or threads from the
brush bar.
Check the turbine duct for blockages. Reassemble brush bar and end cap.
1
5
6
4
9
8
7
Ask the customer to plug machine in
and test that brush bar is spinning and
the plunger is working. If not working
send new turbine head.
2
3
Check inlet plunger for dust/debris.
Check inlet seal for damage.

Dyson DC26 Specifications

General

Suction power	160 AW
Maximum input power	- W
Annual energy consumption	- kWh
Proper use	Home
Noise level	- dB
Removable filter	Yes
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	HEPA
Dirt separating method	Filtering
Type	Cylinder vacuum
Cordless	No
Cleaning type	Dry
Dust capacity	- L
Product color	Blue, Transparent
Tube material	The material the tube is made of.
Dust container type	Bagless
Cord length	5 m
Dust capacity dry	0.68 L
Vacuum brushes included	Hard floor brush

Weight and Dimensions

Weight	5200 g
