Dyson V11 Absolute User Manual

3-4.5hrs
7
Emptying your clear bin
Charging and storing
your machine
Connect to the charger either directly or in
the docking station.
The blue LEDs on either side of the battery
will flash during charging.
When the battery is charged, both LEDs will
light for 5 seconds.
Changing your battery
To remove a battery
Hold your hand under the
battery to support it.
Press the battery release
button and slide the battery
off the handle.
Place the battery on charge.
Where you have additional batteries, we recommend that you
alternate the batteries to maintain even performance.
It's important to fully charge your new machine before using it for the first time,
and after every clean. This is because the battery and monitoring system's
algorithm 'learns' over time, and fully charging your machine helps it to more
accurately calculate and display remaining run time.
To install a battery
Slide the battery onto the
handle until it clicks securely
in place.
Your battery is fully
charged when the
display shows 100%.
Your machine won't
operate if the ambient
temperature is below
0°C (32°F). This is
designed to protect
both the motor and
battery.
Battery empty and
needs charging.
clik
clik
2
1
34
Be careful not to pull
the power trigger while
the clear bin is open
for emptying.
To close the clear bin, push the bin base upwards
until the clear bin and bin base click into place.
clik

Dyson V11 Absolute Specifications

General

Display type	LCD
Dust capacity	0.76 L
Product color	Blue, Nickel
Dust container type	Bagless
Maximum tube length	655.18 mm
Removable handheld vacuum	Yes
Motor power	545 W
Noise level	84 dB
Cleaning type	Dry
Power control	Auto
Number of speeds	3
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	-
Dirt separating method	Filtering
Package depth	154 mm
Package width	271 mm
Package height	900 mm
Package weight	6590 g
Power source	Battery
Charging time	4.5 h
Suction power	38.6 AW
Battery voltage	25.2 V
Maximum input power	- W
Power consumption (standby)	35 W
Number of batteries supported	7
Runtime with motorized brush (high speed)	5 min
Runtime with motorized brush (medium speed)	40 min
Floor nozzle included	No
Vacuum brushes included	Parquet brush, Mini brush, Mini motorized brush

Weight and Dimensions

Depth	250 mm
Width	1286 mm
Height	261 mm
Weight	3050 g
