1.4 Indicator Definition
A
GPS LED Indicator (Blue LED)
Flashing
Searching GPS signal
Continuously bright
GPS fixed
Continuously dark
No GPS fix or initializing
Continuously bright
to dark
Come in sleeping
B
Communication LED Indicator (Green LED)
Flashing
Searching communication
signal
Continuously bright
Communication signal ok
Continuously dark
No communication signal or
initializing
Continuously bright
to dark
Come in sleeping
C
Power Status Indicator (Red LED)
Flashing
No external power
Continuously bright
External power ok
Continuously dark
No battery and no external
power
Continuously bright
to dark
Come in sleeping
1.5 Equipment wiring requirements
The device power supply is DC 10V-40V. The red line is
positive pole while the black line is negative pole.
The negative pole of power supply connects with ground
or the metals. Please do not connect with other ground
lines.
When finishing the power supply wire connection,
please make the plug of power supply to the device.
