POWER ASSISTED BICYCLES
1
2
The Gears work exactly as a normal bike and are
independ of the electric motor.
Understanding the Gears
The Revoshift is fitted on the right side of the handlebars, which consists of a large
shift lever, you can turn the shifter to + side to HIGH gear and - side to LOW gear.
Once riding the 6 speed conventional gearing can be used to thumb shifting up to
low and simple release button to drop back down to High.
(Fig.24)
Lowest Being the easiest and Highest being the hardest.
The gears are pre-set in the factory so should need no adjustment.
Over a period of use the cables will stretch and may need adjustment which is
probably best done at your 3 month service.
Your local bike shop or specialist e.bike shop will offer this service.
( see page 15)
Fig.24
Fig.25
