Specifications
Channels/ Outputs
Single Channel, Dual output via mono
3.5mm sockets.
Inputs Dual 3.5mm stereo jacks, wired in parallel.
Input Impedance 33,000 Ohms
Input Sensitivity 500mV , 200 to 5000Hz
Display
5 High Brightness Light Emitting Diodes
indicating input level and Power On.
Operating Modes
2 – Internal Drive (Microphone), External
Drive (Line In)
Controls
Slide switches for Power On/Off and Input
Selector. Rotary controls for adjustment of
Microphone sensitivity, and Output Level.
Output Waveform High Voltage current limited, pulsed AC
Power Supply Standard 9 Volt Alkaline (PP3)
Battery Life
Variable dependent on load and input, but
estimated at around 8 hours with
continuous use.
Dimensions (approx.) 145mm x 80mm x 50mm
Weight (with battery) 250g
Supplied Accessories
1 off 3.5mm to 2 mm output cable,
1 off 3.5mm to 3.5mm stereo link cable,
4 off Self Adhesive Gel Pads,
1 off user guide.
