REX12-Tx-E electronic circuit protector REX12-Tx-E electronic circuit protector
www.e-t-a.de
2
2045
4
REX12D-TE2-100-DC24V-1A-4A-CL2-E
I
N:
1 A-CL2 typically 50 mV I
N
: 70 % typically 42 mV
I
N:
2 A-CL2 typically 90 mV I
N
: 70 % typically 70 mV
I
N:
3 A-CL2 typically 135 mV I
N
: 70 % typically 95 mV
I
N:
4 A-CL2 typically 180 mV I
N
: 70 % typically 120 mV
REX12D-TE2-100-DC24V-1A-10A-E
I
N
: 1A typically 30 mV I
N
: 70 % typically 28 mV
I
N
: 2A typically 39 mV I
N
: 70 % typically 34 mV
I
N
: 3A typically 48 mV I
N
: 70 % typically 40 mV
I
N
: 4A typically 57 mV I
N
: 70 % typically 46 mV
I
N
: 5A typically 66 mV I
N
: 70 % typically 52 mV
I
N
: 6A typically 74 mV I
N
: 70 % typically 59 mV
I
N
: 7A typically 83 mV I
N
: 70 % typically 65 mV
I
N
: 8A typically 92 mV I
N
: 70 % typically 71 mV
I
N
: 9A typically 101 mV I
N
: 70 % typically 77 mV
I
N
: 10A typically 110 mV I
N
: 70 % typically 83 mV
Fail-safe I
N
: 1 A fail-safe I
N
: 1 A
element I
N
: 1 A- CL2 fail-safe I
N
: 1 A
(integrated fuse I
N
: 2 A fail-safe I
N
: 2 A
adapted to I
N
: 2 A- CL2 fail-safe I
N
: 2 A
respective I
N
: 3 A fail-safe I
N
: 3.15 A
current I
N
: 3 A- CL2 fail-safe I
N
: 4 A
rating I
N
) I
N
: 4 A fail-safe I
N
: 4 A
I
N
: 4 A- CL2 fail-safe I
N
: 4 A
I
N
: 6 A fail-safe I
N
: 6.3 A
I
N
: 8 A fail-safe I
N
: 8 A
I
N
: 10 A fail-safe I
N
: 10 A
I
N
: 1 A/1 A fail-safe I
N
: 1 A/ 1 A
I
N
: 1 A/ -4 A-CL2 fail-safe I
N
: 1 A/ 1 A
I
N
: 2 A/2 A fail-safe I
N
: 2 A/ 2 A
I
N
: 2 A/2 A-CL2 fail-safe I
N
: 2 A/ 2 A
I
N
: 3 A/3 A fail-safe I
N
: 3.15 A/ 3.15 A
I
N
: 3 A/3 A-CL2 fail-safe I
N
: 4 A/ 4 A
I
N
: 4 A/4 A fail-safe I
N
: 4 A/ 4 A
I
N
: 4 A/4 A-CL2 fail-safe I
N
: 4 A/ 4 A
I
N
: 6 A/6 A fail-safe I
N
: 6.3 A/ 6.3 A
I
N
: 1 A-4 A-CL2 Fail Safe I
N
: 4 A
I
N
: 1 A- 1 A fail-safe I
N
: 16 A
Operating voltage OFF at typically U
B
< 16.0 V
sensing for ON at typically U
B
> 19.0 V
low voltage hysteresis typically 2 V
with automatic OFF and ON operation
ON delay
- when Power ON channel 1: typically 100 ms (REX12-TAx-E)
channel 2: typically 200 ms (REX12-TAx-E)
channel 1: typ. 1.500 ms (REX12D-TE2-E)
channel 2: typ. 1.600 ms (REX12D-TE2-E)
- when operating via channel 1: typically 5 ms
the ON /OFF-button or channel 2: typically 100 ms
- after low voltage channel 1: typically 5 ms
channel 2: typically 5 ms
Disconnection of the load circuit
- Manually at the device via the
ON/OFF button
- after an overload / short circuit
disconnection with saving (no automatic
reset)
- temporarily in case of low voltage
- with no operating voltage
Switching on the load circuit
- ON/OFF button Device can only be switched on when
operating voltage is applied
- Applying the The device starts operation
operating voltage in last saved condition.
Technical data (T
U
= +23 °C, U
B
= DC 24 V)
REX12-Txx-xxx circuit protectors
REX12-TA1-107-DC24V-xA-E 1-channel
REX12-TA2-107-DC24V-xA/xA-E 2-channel
REX12D-TE2-100-DC24V-xA-xA-E 2-channel
The REX12-TAx-E is operated at the EM12-T-E in standard mode.
The REX12D-TE2-E can be operated at the EM12D-T as well as
at the EM12-T-E. The operating mode EM12D-T (COM-Mode) or
the EM12-T-E (standard mode) is recognized automatically.
The following indications refer exclusively to the standard mode.
Operating voltage U
B
DC 24 V (18...30 V)
Quiescent current I
0
REX12-Tx1-E 1-channel in ON-condition: typically 5 mA
REX12-TA2-E 2-channel in ON-condition: typically 8 mA
REX12D-TE2-E 1A-4A 2-channel in ON-condition: typically 9 mA
REX12D-TE2-E 1A-10A 2-channel in ON-condition: typically 12 mA
Reverse polarity protection Yes
Power failure-bridging time up to 10 ms
Current rating I
N
Currents:
REX12-Tx1-E 1 A, 2 A, 3 A, 4 A, 6 A, 8 A, 10 A
REX12-TA2-E 1 A/1 A, 2 A/2 A, 3 A/3 A, 4 A/4 A, 6 A/6 A
REX12D-TE2-E 1 A-4 A, 1 A-10 A Condition as delivered
max. current rating
Visual status indication
Green: Load circuit connected
of
operating mode Green/Orange flashing:
via LED load current Warning limit 90 % reached
Orange: Overload or short circuit until
disconnection
Red: - after an overload /
short circuit disconnection
- after undervoltage release
of operating voltage in ON
condition with autoreset
LED off: Device switched off by means of
ON/OFF momentary switch or
no operating voltage
Load circuit
Load output Power MOSFET switching output
(high side switching)
Load current warning limit typically 0.9 x I
N
(I
WLimit
)
hysteresis typically 5 %
Overcurrent trip typically I
OL
: I
N
x 1.05 t
OL
: 3s
(I
OL
) typically I
OL
: I
N
x 1.35 t
OL
: 0.5s
with trip times (t
OL
) typically I
OL
: I
N
x 2.00 t
OL
: 0.1s
typically I
OL
: I
N
x 2.50 t
OL
: 0.012s
short circuit- typically under short-
trip time (t
SC
) circuit conditions (I
SC
) t
SC
: 0.002 s
2)
see time/current characteristic
Influence of ambient see temperature factor table
temperature on
overload disconnection
and load current - warning limit
Voltage drop in load circuit at I
N
and at I
N
70 % for
REX12-Txx-E
between LINE+ and LOAD+
I
N
: 1A typically 180 mV I
N
: 70 % typically 125 mV
I
N
: 1 A-CL2 typically 180 mV I
N
: 70 % typically 125 mV
I
N
: 2A typically 110 mV I
N
: 70 % typically 80 mV
I
N
: 2 A-CL2 typically 110 mV I
N
: 70 % typically 80 mV
I
N
: 3A typically 120 mV I
N
: 70 % typically 85 mV
I
N
: 3 A-CL2 typically 130 mV I
N
: 70 % typically 90 mV
I
N
: 4A typically 115 mV I
N
: 70 % typically 80 mV
I
N
: 4 A-CL2 typically 180 mV I
N
: 70 % typically 120 mV
I
N
: 6A typically 170 mV I
N
: 70 % typically 110 mV
I
N
: 8A typically 160 mV I
N
: 70 % typically 105 mV
I
N
: 10A typically 180 mV I
N
: 70 % typically 120 mV
2) depending on power source
Technical data (T
U
= +23 °C, U
B
= DC 24 V)
