Page 12 Rev 3.01 8-0904
The air filter box is located on the left side of the
engine under the body cover. It is a black box about
6” square and is attached to the crankcase with two
bolts and the carburetor by a tube.
To clean the filter
Remove the air filter box cover.
Remove the filter element from the air box.
Wash the element in a non-flammable solvent such
as Air-Filter cleaner from your local auto parts
dealer.
1. Dry the element completely before
continuing.
2. Soak the element in clean engine oil until
completely saturated.
3. Squeeze out the excess oil until the element
does not drip any oil.
4. Allow the element to dry then reinstall the
element and cover.
