Unfolding steps
1. Press the rear brake in the direction of the arrow in the figure (a) until the
folding hook release from the opening located on the rear brake. Then, lift the
handlebar until it reaches the working position and the locking bolt comes into
place, like in figure (b).
2. Raise the two handles of the handlebar until they automatically return to the
work position, figure (c).
3. Push the lock lever in the direction of the arrow in Figure (d) and lift
handlebars to desired height. Now press button shown in Figure (e) and fix it in
one of the two holes, as desired.
a b c
d e
