E-Wheels EW-01 User Manual

4
Operation of Scooter:
1. Turning on the power
Put key in ignition and turn clockwise to turn key on. Turn-key counter-
clockwise to power off when you stop. (Fig a)
2. Speed Control
Speed is controlled by the black twist grip throttle. Twisting the throttle
grip towards you will increase the speed. Releasing the throttle grip will
reduce the speed. (Fig a)
3. Battery Voltage Indicator
The battery level indicator will show when the scooter is on. The battery
is 48 volts thus the battery indicator when full should read a minimum of
48 volts although often the battery voltage will read higher because many
batteries when fully charged will read greater than 48 volts. The battery
read out simply indicates the voltage remaining on the battery. (fig a)
(fig a)

E-Wheels EW-01 Specifications

General

Speed:	Up to 11mph
Distance:	30 miles per charge (distance varies on terrain, riders weight, road surface, etc.)
Turning Radius	33”
High/ Low Speed switch:	N/A
Throttle Type:	Variable Twist Throttle
Braking System:	Rear Drum Brakes
Drive System:	450 Watt Rear Hub Motor
Front Seat: Type	Folding/Collapsible Chair with Backrest
Front Seat:	21 ½ “
Rear Foot Rest:	N/A
Front Basket:	8” x 8” x 10”
Front:	Frame shock absorbers
Rear:	N/A
Warranty:	Limited – 3 Year Warranty
Safe Gradient:	18°
Power:	Electric
Watts:	450 Watt
Amps:	12 AH
Volts:	48 Volts
Motor Type:	Rear Wheel Hub Motor
Batteries:	(1) Lithium Ion Battery 78 Cell with BMS
Charger:	48-volt Smart Charger included
Battery Indicator:	Yes
Forward/Reverse switch:	Yes
Key Start:	Yes
Headlight:	N/A
Rear lights:	N/A
Reflectors:	Yes (rear only)

Weight and Dimensions

Weight Capacity	300Lbs
Front seat: Size	13 ½ “x 12 ½ “x 14”
Steering Height	30” from Ground
Dimensions:	37” x 22” x 33” Folded: 38” x 23” 22”
Floor Clearance:	3”
Front tire size:	7” tire type: 200 x 50
Rear tire size:	10” tire type: 10 x 2.125
Carton Size:	Shipped fully assembled on pallet – 48” x 30” x 34”
Scooter Weight:	69lbs with batteries
