Committed to Quality and Reliability!
3
Main Components
② ③ ④ ⑤
⑦
⑧
①
⑥
① the left handlebar ② the rear brake grip ③ the front light switch
④ the horn button ⑤ the power indicator ⑥the ignition switch ⑦the front
brake switch ⑧the rolling handlebar
Main Technical Parameters
Main technical parameters of whole vehicle Main technical parameters of motor
L×W×H(mm) 1800×800×1120 Motor type Brushless wheel hub motor
Wheel track(mm) 1400 Rated continuous output power（W） 250/350
N.W.(kg) 36 Rated output rotation speed（r/min） 240±10
Rated Loading Capacity(Kg) 150 Rated voltage(V) 36
Max. Forward Speed(km/h) 28 Rated output torque（N. m） 12
Distance per charge(km) 30-50 Controller
Main technical parameters of storage battery Under-voltage protection value(V) 31.5±0.5
Battery type Lead-acid Maintenance-free battery Over-current protection value(A) 15±1
Battery capacity(Ah) 12 Charger
Nominal voltage(V) 36/48 Input Voltage AC110V/220v 50Hz
Weight of battery pack（kg） 16.8/26.8 Max. output power(w) 110
