2.2 Baery charging on page 15
2.1.10 The XLR charger connector
Figure 27: The XLR charger
connector
The XLR charger connector, which is located on the right-hand side of the


Warning:
Make sure that the baery charger that is used with the vehicle has a drive inhibit funcon that is correctly
connected for use with the controller. The maximum voltage on the inhibit pin must not exceed 3V if a baery
voltage is to be detected when the baery charger is connected. If you are not sure, ask your dealer or vehicle
manufacturer.
The XLR charger connector on the Remote is to be used exclusively for the intended purpose. Warranty will be
voided if any unauthorised device is connected to this port.
2.1.11 The LiNX Communica�ons Bus connector
Figure 28: The LiNX
Communica�ons Bus
connector




