5 - 11
MAINTENANCE
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
5
TRANSPORTING VEHICLE
TOWING
This vehicle is not designed to be towed
It is recommended that the vehicle be moved by placing the entire vehicle on a trailer, flatbed truck or other suitable
transport.
NEUTRAL LOCK
To prevent the driven clutch from turning the rear wheels during service operations, a neutral lock is located on the
direction selector
To operate:
Turn key switch to ‘OFF’ and lift seat. Pull out and rotate the neutral lock pin handle so that the pointed portion of the
handle is to the side of the direction selector cam. Move direction selector towards the area between ‘F’ and ‘R’. Dur-
ing that motion the pin will snap into the hole in the direction selector mounting bracket preventing any movement.
When in this position, the direction selector remains locked in the neutral position. To unlock the direction selector,
pull the neutral lock pin handle out and rotate until the pointed portion of the handle fits into the hole in the direction
selector cam.
HAULING
To reduce the possibility of severe injury or death while transporting the vehicle:
Secure the vehicle and contents.
Never ride on the vehicle being transported.
Always remove the windshield before transporting.
If the vehicle is to be transported at highway speeds, the sun top must be removed and the seat bottom secured.
When transporting vehicle below highway speeds, check for tightness of hardware and cracks in sun top at mounting
points. Always remove windshield when transporting. Always check that the vehicle and contents are adequately
secured before transporting. The rated capacity of the trailer or truck must exceed the weight of the vehicle (see
2
1
3
Hole in Direction
Selector Cam
Unlocked
To Next Page
