E-Z-GO Freedom RXV - Gas - Capacities and Replacement Parts

Page 14
OPERATION AND SERVICE INFORMATION
Owner’s Guide
Read all of manual to become familiar with this vehicle. Pay attention to all NOTICES, CAUTIONS, WARNINGS and DANGERS.
B
CAPACITIES AND REPLACEMENT PARTS
Steering Assembly - excessive play, loose or missing
hardware

Tie Rods - excessive play, bent rods, loose or missing
hardware

Rear Axle - fluid level, oil leakage, noise, loose or
missing hardware

Rear Axle - drain & replace fluid R
Rear Suspension - shock oil leakage, worn bushings,
loose or missing hardware

Front Suspension - strut oil leakage, excessive play in
hubs or kingpins, worn bushings, loose or missing
hardware

Front Wheel Alignment - unusual tire wear C&A C&A C&A
Fuel Level

Fuel System - leaks at tank, cap, system lines for
cracks/deterioration, filters, pump

Fuel Filter R
Spark Plug R
Throttle/Governor Linkage - operation & governed
speed

Air Filter Element - check & replace as necessary

Drive Belt - cracks, frayed, excessive wear

REMARKS
before each use DAILY WEEKLY
20 rnds/20 hrs 100 miles/160 kms MONTHLY
60 rnds/60 hrs 300 miles/500 kms QUARTERLY 125 rnds/125 hrs 600miles/1000 kms SEMI-ANNUAL 250 rnds/250 hrs 1200miles/2000 kms ANNUAL 5 YEARS PAGE
Fig. 19
**Initial oil change after 8 hours of run time.
FLUID QUANTITY
Fuel Tank
5.1 gal (19.3 liters) 87
Octane minimum
Engine Oil 1.25 L (1.3 qt.)
Rear Axle Lubricant Oil SAE 30 1.5 L. (51 oz.)
Fig. 20 Capacities
ITEM PART NUMBER
Oil Filter E-Z-GO P/N 607454
Air Filter E-Z-GO P/N 28463G01
Spark Plug NGK BPR2ES (E-Z-GO P/N 607462)
Starter/Gen. Belt E-Z-GO P/N 606138
Clutch Belt E-Z-GO P/N 606136
Fuse ATC 10A (E-Z-GO P/N 35212G07)
Headlight Bulb 894 (E-Z-GO P/N 74004G01)
Turn Signal Bulb 912-NA (E-Z-GO P/N 74005G01)
Tail Light Bulb 2057 (E-Z-GO P/N 604311)
Fig. 21 Replacement Parts
