Eachine LCD5802D User Manual

Specification:
Model
Name
5.8G FPV Display
LCD Screen
Screen size: 7 Inch
Resolution: 800*480
Display Ratio: 16:9
View Angle: 6 o'clock
Brightness: 300cd/m² with high brightness backlight LED
Video delay
Video time-delay less than 20ms
Interface
Antenna
2 X RP-SMA male
DC055
To charge the battery
AV Jack
External video signals input or internal Audio signal output
Card slot
TF-Card, Support up to 32G(C10 recommend)
DVR
REC size: VGA / D1 / HD Selectable
REC sound: ON / OFF Selectable
REC time: OFF / 3min / 5min / 10min Selectable
Frame rate: 30 Frames
Compress format: MJPEG
Record file format: AVI
Languages
English,German,French,Spanish,Ltalian,Chinese,Russian,Japanese
Power adapter: DC12V/2A (DC3.5 interface)
Battery: 7.4V/2000mAh,
DVR module ON: Each full charge revive around 4hr working time
DVR module OFF: Each full charge revive around 3hr working time
Power Consumption:
* Normal mode: The device operating current of 400mA at 7.4V;
* Record Mode : The device operating current of 620mA at 7.4V;
* Built-in battery maximum charge current of 800mA;
Wireless
Frequency Table(MHz)
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
Band A
5865
5845
5825
5805
5785
5765
5745
5725
Band B
5733
5752
5771
5790
5809
5828
5847
5866
Band E
5705
5685
5665
5645
5885
5905
5925
5945
Band F
5740
5760
5780
5800
5820
5840
5860
5880
Band R
5658
5695
5732
5769
5806
5843
5880
5917
Body
Dimension: 180mm * 120mm * 50mm(Notc:Sunshield height:28mm)
Weight: 430g(not included antennas)
* Note: Cannot record video input from AV port. *
