Eachine Wizard X220HV User Manual

-7-
Wiz a rd X 2 20 H V
QUICK START GUIDE
Support Betaflight configurator
Speedybee App: iOS 10.0+; iPhone 4S, iPad3;
Androd 4.3+
Output power: 0dBM
Sensitivity: -94dBM
External interface: BROADCAST SWITCH, TX, RX,
3-5V DC Input, GND
Transmission speed: Bidirectional 1K/S
Bluetooth protocol: Bluetooth Specification V4.0 BLE
Transmission distance: 30 meters
Frequency range: 2400MHz-2483.5MHz (2.4G ISM
Band)
Baud rate: 2400, 4800, 9600, 14400, 19200(default),
28800, 38400, 57600, 76800, 115200, 230400
Working voltage: 3.3V-5.0V
Working current: 8.3mA-10mA
Weight: 1.4g
Size: 27*15*4.5mm
8.0 SpeedyBee bluetooth module
