In-dash mounting template for Cuda 128 and Cuda 168.
NOTE: This figure is printed to scale. For use with FM-6 mount kit.
Top
Cut along this line
ALWAYS VERIFY DIMENSIONS.
Measure the reference cross-hair below to
confirm that this template is printed to the correct
scale. The vertical line and the horizontal line
should each be 2 inches long (50.8 mm.)
Print only at 100% scale – do not fit to page, do not enlarge or shrink.
