6. Illustrations & Parts List
6.4 Tape Head Carriage (Upper Belt Drive)
- 15 -
Description Part Number Qty
1 Bracket - Must specify Left or Right FJG-1A-130L or FJG-1A-130R 2
2 Belt Guard - Must specify Left or Right
FJ-2A-135L or FJ-2A-135R
2
3 Conveyor Belt
1520X50X5MM
2
4 Shaft FJ-3A-415 12
5 Drive Wheel FJ-3A-419M 2
6 Motor Support FJ-2A-126 1
7 Motor Cover FJ-3A-437 1
8 Upper Transmission (Drive) Axle FJ-1D-120 1
9 Motor CV200-20ZG3 1
10 Wheel FJ-3A-416 12
11 Wheel FJ-3A-413 2
12 Upper Tension Axle FJ-2A-123 1
13 Retaining Plate FJ-1A-703 1
14 Brush Support FJ-1A-701 1
15 Support Bars* FJG-1A-131.2 2
16 Supporting Shaft FJ-1-440 1
17 Shaft FJ-3A-807 1
18 Spring Holder FJ-3A-808 1
19 Fixed Block FJG-1A-127 1
20 Compression Spring FJ-1A-930 1
21 Sliding Block FJ-3A-806 1
22 Motor Sprocket (16 teeth) FJ-2A-132.1 1
23 Chain
06B200
1
24 Bearing Bracket FJ-1D-304 2
25 Lower Sprocket (13 teeth)
FJ-2A-132
1
26 Switch Stop/Pointer FJ-3A-450 1
27 Bearing 6003Z 1
If you have a T200L, please be sure to add a -2L to the end of the part number
for any part marked with an *
If you have a stainless steel model, please add -SS to any metal part when
ordering.
