- 17 -
6. Illustrations & Parts List
6.5 Side Conveyor System (Continued)
Description Part Number Qty
1 Right Lead Nut FJG-1A-927 2
2 Lead Screw (Left/Right)* FJG-1A-155 1
3 Cover Plate - Must specify Left or Right
FJG-1A-169L or FJG-1A-169R
1/ea
4 Side Belt Cover - Must specify Left or Right FJG-1A-152L or FJG-1A-152R 1/ea
5 Conveyor Support Base - Must specify Left or Right
FJG-1A-151L or FJG-1A-151R
1/ea
6 Belt 1867X50X5mm 2
7 Metal Drive Wheel FJG-1A-148 2
8 Transmission Shaft FJ-1A-200 2
9 Driver Wheel Sleeve FJG-1A-208 2
10 Conveyor Bearing 6005 2
11 Bearing Base FJ-3A-116 2
12 Motor Mount Panel FJ-1A-302 2
13 Sliding Sleeve FJ-1A-920 2
14 Guide Shaft* FJ-1A-201 1
15 Lead Screw (Left/Right)* FJG-1A-154 1
16 Motor - Standard RPM 1670 CV200-20ZG1/G2 2
17 Locating Pins FJG-1A-160 4
18 Connection Pole FJG-1A-162 4
19 Orientation Plate FJG-1A-158 2
20 Left Lead Nut FJG-1A-156 2
21 Tensioning Shaft FJG-1A-141 2
22 Tension Wheel Sleeve FJG-1A-207 4
23 Wheel FJG-1A-149 2
24 Width Adjustment Gear FJ-1A-129 2
25 Short Roller Assembly* FJG-1A-182/183S 12
26 Long Roller Assembly* FJG-1A-182/183L 10
27 Screw Retainer Closed Assembly FJ-SR-C-ASSY 3
28 Screw Retainer Open Assembly FJ-SR-O-ASSY 1
29 Handle Mount Assembly
FJG-1A-196A
1
Handle FJG-1A-193 3
Hub FJG-1A-944 1
Handle Mount
FJG-1A-917
1
Parts
in 29
If you have a T200L, please be sure to add a -2L to the end of the part number
for any part marked with an *
If you have a stainless steel model, please add -SS to any metal part when
ordering.
