Eagle T200 - Page 19

- 19 -
6. Illustrations & Parts List
6.6 Tape Head (Continued)
Description Part Number Qty
1 Side Plate FJ-01-17 1
2 Guide Pulley Assembly - see pg 22 for breakdown
FG-GUIDEPA
1
3 One-Way Knurled Roller Assembly - see pg 22 for breakdown
FJ-E-34
1
4 Blade Carrier FJ-01-04 1
5 Front Roller Assembly - see pg 20 for breakdown FG-FRROLLERA 1
6 Block
FJ-01-00
1
7 Shaft
FJ-00-12
2
8 Stop
FJ-40-00
2
9 Side Plate (x3)
FJ-01-02
1
10 Shaft
FJ-00-02
1
11 Shaft
FJ-00-07
1
12 Shaft
FJ-00-06
4
13 Side Plate (x2)
FJ-01-16
1
14 Shaft Cover FJ-02-09 1
15 Back Roller Side Plate Assembly - see pg 21 for breakdown
FG-BKROLLERA
1
16 Brass Washer
FJ-02-04
1
17 Connecting Lever FJ-01-14 1
18 Knife Blade Assembly - see pg 23 for breakdown
KNIFE BLADE ASSY
1
19 Knife Leveling Piece
FJ-01-01
1
20 Tape Hub Assembly - see pg 24 for breakdown FG-TAPEHUBASSY 1
21 Tension Spring - Must Specify Upper or Lower FJ-H-07-U or FJ-H-07-L 1
22 Extension Spring Axis
FJ-00-01
1
23 Extension Spring
FJ-H-04
1
If you have a stainless steel model, please add -SS to any metal part when
ordering.
