Chapter 1 Introduction
The 210L is a broadband solid state amplifier covering the frequency spectrum from 15
KHz to 12 MHz. It is rated at 10 watts of RF power with low harmonic and intermodulation
distortion. Over 10 watts of saturated power can be produced with increased distortion
products. A highly linear Class A design, the 210L will amplify inputs of AM, FM, SSB,
pulse and any complex modulation signals. The amplifier has 40 dB gain it is
unconditionally stable and will not oscillate even with combinations of mismatched source
and load impedance. It is protected against failure due to output load mismatch.
. An integral power supply permits operation from 115/230 single phase AC power.
1.2 INSTRUMENTATION IDENTIFICATION
Each amplifier is identified by a serial number tag on the back panel of the unit. Both the
model number and the serial number should be quoted to identify specific unit.
1.3 SPECIFICATIONS
Physical and electrical specifications are listed in Table 1-1 below
