E&R Classic KPN5000 - Machine Oiling Procedure

17
openthehookcover.
Openthehingedlatchofbobbincaseandtake
itoutofthemachine.
Raisetheneedletoitshighestpositionand
Whencaringforyourmachine,orcleaningit,unthreaditanddisconnectthepresser,
evenwhenyouchangetheneedle.
DismantlingandAssemblingHookRace
CAREOFYOURMACHINE
Openthehookraceringholders
andremovethehookracering.
Disconnectyourmachinefromthepowersouce
Removethehook.
*Cleanthehookracewitha
brushandasoftdrycloth.
Holdthehookbythecenterpinandfititcarefullybackintothehookrace,
formingaperfectcirclewiththeshuttledriver.Attachthehookracering
makingsurebottompinfitsintothenotch.Lockthehookraceringby
turningtheholdersbackintoposition.Insertthebobbincase.Threadthe
machineandbobbin,connectthemachinetothepowerpointandsewafter
switchingonthemachine.
TOdismantlehoodrace:
Toassemblehookrace:
Removetheneedleandthepresser
foot.
Unscrewtheneedleplatesetscrews
andremovetheneedleplate.
tightenscrews
Withabrush,cleanoutdustandlint
cloggingonthefeeddogteeth.
Replacetheneedleplate.
CleaningtheFeedDogs
Fittedinthemachine.
NOTE:Itiseasierifyoulaythemachineonitsbacktoreplacetherace.
Oilwithone
dropofoil.
