SettingSpoolPins
WindingtheBobbin
Tousepullupthespoolpin.Pushdown
Upperthread
Upper
thread
Hole
Tangle
Openthehookcover.
Raisetheneedlebyturningthebalance
wheeltowardyou.
Takeoutthebobbincasebyholdingthe
latch.
Wheninsertingthebobbincase,place
thehornintotherecessofthehook
race.
forstorage.
Ifthethreadwouldslipdownfromthe
spool.threadthroughtheholeofspoolpin
asshown.
Switchonthemachine.
Drawthreadfromspool.Guidethethreadaroundthebobbinwinderthreadguide.
Insertthethreadthroughoneoftheholesinthebobbinfromtheinsidetotheoutside.
Putthebobbinonthebobbinwinderspindle,andpushittotheright.
Withthefreeendofthethreadheldinyourhand,depressthefootcontrol.Stopthemachinewhenithasmadeafewturns,andcutthethreadclosetotheholein
thebobbin.Depressthefootcontrolagain.
Whenthebobbinisfullywound,itwillbestopautomatically.
Returnthebobbinwindertoitsoriginalpositionbymovingthespindletotheleft,andcutthethread.Turntheclutchknobclockwise.
RemovingorInsertingtheBobbinCase Switchoffthemachinewhiledoingthis.
Recessofthehookrace
Horn
Crossthecottoninafigureofeight
forgoodtension.
