Amplifier Function Map / Use
Inline Amplifier
Mic Switch:
Mic On (High) Mic On (Low)
Phone Call Mode Mic Mute
Mic Mute Indicator LED:
bright blue = Mic On (High),
dark blue = Mic On (Low),
purple = Phone Call Mode,
red = Mic Mute
MODE SWITCH
Headset Connectivity
Aux Input for
Phone & Music *Xbox Chat Input
Bottom View Top View
Chat Control
Variable Mic Monitor
Bass Controls
Treble Controls
Chat Boost Indicator LED
Game Volume Controls
