EarthQuake VTEK Series - VTEK Coaxial Speaker Specifications; Woofer and Tweeter Details; Performance Specifications; Included Components

All specifications are subject to change without notice.
8
EARTHQUAKE SOUND • INSTALLATION 9
VTEK COAXIAL SPECIFICATIONS
VTEK-42
Woofer
Model
VTEK-693
Tweeter
Sensitivity
Frequency Response
Nominal Impedance
Recommended
Amplifier Power
VTEK-52
VTEK-52Xi
VTEK-62
VTEK-62Xi
VTEK-62: 4-Ohm
VTEK-62Xi: 2-Ohm
VTEK-57
VTEK-57Xi
Nominal Impedance
Mid-range
• 4” diameter
• Glass fiber cone
• 25mm ASV VC
• NOMEX/ROMEX
spider assembly
• PistonMax™
• 20mm
• Silk dome
• Neodymium magnet
• Multiple mounting
positions
75Hz - 22kHz (±3dB)
89 dB @ 1W/1M
50 - 300 Watts
4 ohm
N/A
• 5-1/4” diameter
• Glass fiber cone
• 25mm ASV VC
• NOMEX/ROMEX
spider assembly
• PistonMax™
•
• Silk dome
• Neodymium magnet
• Multiple mounting
positions
20mm
55Hz to 22kHz (±3dB)
89 dB @ 1W/1M
50 - 400 Watts
VTEK-52: 4-Ohm
VTEK-52Xi: 2-Ohm
N/A
• 5" x 7” diameter
• Glass fiber cone
• 25mm ASV VC
• NOMEX/ROMEX
spider assembly
• PistonMax™
• 20mm
• Silk dome
• Neodymium magnet
• Multiple mounting
positions
40Hz to 22kHz (±3dB)
90 dB @ 1W/1M
50 - 400 Watts
VTEK-57: 4-Ohm
VTEK-57Xi: 2-Ohm
N/A
• 6-1/2” diameter
• Glass fiber cone
• 25mm ASV VC
• NOMEX/ROMEX
spider assembly
• PistonMax™
• 20mm
• Silk dome
• Neodymium magnet
• Multiple mounting
positions
45Hz to 22kHz (±3dB)
90 dB @ 1W/1M
50 - 500 Watts
N/A
• 6" x 9” diameter
• Glass fiber cone
• 30mm KSV VC
• NOMEX/ROMEX
spider assembly
• PistonMax™
• 20mm
• Silk dome
• Neodymium magnet
• Multiple mounting
positions
25Hz-22kHz (±3dB)
92 dB @ 1W/1M
50 - 700 Watts
4 ohm
• 2” (50.8mm)
VTEK-62 INCLUDE
•
w/ built-in adjustable 20mm silk dome tweeters
• Two matching metal woofer grilles with trays
• Butyl adhesive putty for woofer grilles
• Eight(8) speaker mounting clips
• Eight(8) 1.35” (34.925mm) sheet metal screws
• Two sets of specially designed speaker cables
Two VTEK 6-1/4” glass fiber cone woofers
VTEK-52 INCLUDE
• Two VTEK
w/ built adjustable 20mm silk dome tweeters
• Two matching metal woofer grilles with trays
• Butyl adhesive putty for woofer grilles
• Eight(8) speaker mounting clips
• Eight (8) 1” (25.4mm) sheet metal screws
• Two sets of specially designed speaker cables
5-1/4” glass fiber cone woofers
VTEK-693 INCLUDE
• Two VTEK
w/ built-in adjustable 20mm silk dome tweeters
and two-inch mid-range tweeters
• Two matching metal woofer grilles with trays
• Butyl adhesive putty for woofer grilles
• Eight(8) speaker mounting clips
• Eight(8) 2” (50.8mm) sheet metal screws
• Two sets of specially designed speaker cables
6" x 9” glass fiber cone woofers
VTEK-57 INCLUDE
• Two VTEK
w/ built-in adjustable 20mm silk dome tweeters
• Two matching metal woofer grilles with trays
• Butyl adhesive putty for woofer grilles
• Eight(8) speaker mounting clips
• Eight (8) 1.5” (38.1mm) sheet metal screws
• Two sets of specially designed speaker cables
5" x 7” Carbon fiber cone woofers
VTEK-42 INCLUDE
• Two VTEK
w/ built-in adjustable 20mm silk dome tweeters
• Two matching metal woofer grilles with trays
• Butyl adhesive putty for woofer grilles
• Eight(8) speaker mounting clips
• Eight(8) 1” (25.4mm) sheet metal screws
• Two sets of specially designed speaker cables
4” glass fiber cone woofers
GRILLE 4 SHEET METAL
SCREWS PER SPEAKER
GRILLE TRAY
CUSTOM SPEAKER INSTALLATION
4 SHEET METAL SCREWS PER SPEAKER
SPEAKER
FACTORY REPLACEMENT INSTALLATION
MOUNTING CLIPSFACTORY CUTOUT
NOTE: Hand tighten the screws
in a crisscross pattern to
avoid bending the speaker basket or stripping screws.
INSTALLATION APPLIES
TO BOTH COMPONENT
AND COAXIAL SPEAKERS
NOTE:
INSTALLATION APPLIES
TO BOTH COMPONENT
AND COAXIAL SPEAKERS
NOTE:
