Page 5
800-345-6007
EARTHQUAKE, Division of Ardisam, Inc.
SpECIFICATIONS AND ElECTRICAl REQUIREMENTS
ApplICATION CONDITIONS
The Earthquake Mini Electric Log Splitter has been
designed as a home use model only. It is designed for
operating under ambient temperatures between 40° F.
and 105° F. and install at altitudes no more than 3,250 ft.
above M.S.L. The surrounding humidity should be less
than 50% at 100° F. The log splitter can be stored or
transported under ambient temperatures between -10° F.
and 130° F.
SpECIFICATIONS
Model Number W1000
Motor 120V~50Hz
1500W IP54
Log Capacity
Diameter * 2 - 10 inches
Length 20 inches
Splitting Force 4 ton
Hydraulic Pressure 2,300 psi
Hydraulic Oil Capacity 3.75 quarts
Overall Size
Length 37 inches
Width 11 inches
Height 20 inches
Weight 93 lbs.
*The diameter of the log is indicative - a small log can be dif-
ficult to split when it contains knobs or a particularly tough fiber.
On the other hand, it may not be difficult to split logs with regu-
lar fibers even if its diameter exceeds the max. figure indicated
above.
ElECTRICAl REQUIREMENTS
Connect the main leads to a standard 110V ±10% elec-
trical supply which has protection devices under-voltage,
over-voltage, over-current, as well as a residual current
device (RCD) with a maximum residual current of 0.03A.
