Warning: please make sure the massage chair is POWER OFF before maintenance and repair.
As the voltage is 220-240VAC, please make sure the plug is removed from outlet for safety
before processing operations as follow.
VII. Maintenance of the back rest
1. Disassembly of the back pad
① You can find a zip of the back pad on the top of the back rest.
② Unzip, and disconnect the connector of heating leaf, then the back pad can be removed.
③ If it’s damaged, a new one should be replaced. If the heating leaf fails, you can replace it too.
④ Proceed in the reverse order of disassembly when replacing a new one.
2. Disassembly and replacement the rear cover of the back rest
If disfiguring damage or crack happened, you can proceed as follow:
① Find 4 pieces of screws fixing the rear cover.
② Slacken and remove them with a plus screwdriver.
③ Then the rear cover can be removed.
④ If it’s damaged, a new one should be replaced.
Attention: Take care not to damage the rear cover to avoid bad external appearance. Proceed in the reverse order
of disassembly when assembling the rear cover.
Zip of the back pad
Screws tightening the rear cover
（4pcs）
Heating leaf Connector of heating leaf
