5
S upport C leat
Fixed S helf
4
Attach Support Cleat
Figure 7
A tta c h u s in g
#8 x 50m m B lack S crew s
#8 x 50m m S crew
Track is attached
76" from floor
C enter
Unit
Inside w idth
is 23 7/8"
Maximum inside
w idth is 34 7/8"
O verall outside w idth is 96"
For an exact fit on a
w all less than 96" w ide,
one section of rod(s)
m ust be cut dow n.
Shelves can also be
c u t to s iz e .
O n c e u n it is in its fin a l p o s itio n ; a tta c h th e s u p p o rt
c le a t to th e b a c k w a ll, u n d e rn e a th a fix e d s h e lf.
Attach support cleat tightly underneath a fixed shelf
w ith # 8 x 5 0 m m s c re w s o r to g g le b o lts .
Figure 7.
NO TE: If you w ill be using draw ers in your unit,
attach support cleat underneath the bottom shelf.
F o r a d d e d s ta b ility , d rill a 3 /3 2 " h o le th ro u g h th e fix e d
s h e lf in to th e s u p p o rt c le a t a n d s e c u re th e s h e lf to th e
support cleat w ith #8 x 50m m screw s.
To Next Page
