Attach track. Measure desired height at the corner of both
walls. 75.5" above the floor is recommended.
The track height can be adjusted depending on the
individual needs. Using a level, draw a straight line on
each wall out from the corner.
Mounting track 75.5" from the floor will put the top of vertical
panels 84" above floor.
Locate studs. Tap the wall or use an electronic stud
finder to locate studs. Mark wall
1
⁄2" below horizontal line.
Studs (2 x 4) are usually located on 16" centers
measured from the left or right side.
Lay out the closet design to determine approximately
where vertical panels will be located. Corner units are
30" wide. Mark locations on wall below horizontal line.
1
Vertical panel location
Ma
rk wall
2
Mark vertical panel locations
30"
Wide
Do not install track all the way into the corner in order to leave
room for the corner cleats.
Level line 75.5" from the floor,
then mark stud locations.
