EasyIO FD-20i User Reference v1.2
Physical Input Terminal
Digital Imput Block Channel
DI 1
DI 1
DI 2
DI 2
DI 3
DI 3
DI 4
DI 4
DI 5
DI 5
DI 6
DI 6
DI 7
DI 7
DI 8
DI 8
DI 9
DI 9
DI 10
DI 10
UI1
DI 11
UI2
DI 12
UI3
DI 13
UI4
DI 14
UI5
DI 15
UI6
DI 16
UI7
DI 17
UI8
DI 18
UI9
DI 19
UI10
DI 20
