FLAT ROOF MODEL: EF-D3008
CUSTOMER CHECK LIST: 1 of 2
2
1800mm WALL SHEET
NARROW – 710mm (w)
SN1
240 SELF DRILLING SCREW ESCREW12
40 POP RIVET ERIVET-S
6 INTERNAL CHANNEL JOINER EICJ
4 BUTT HINGE HINGE64
1 DOOR PLATE EDP
3 PADBOLT & HASP EPAH
NOTE: Where possible, most components have been marked with Part Numbers for easy identification.
Other components not able to be marked can be easily identified by their description, sketches and
sizes shown on the Pack List and throughout this instruction.
