Lateral Supports
12”-18”W
PNG50176
Independent
Knee pads PNG50384
Independent Roho
®
Knee pads PNG50385
Remove ratchet handle and hardware from the knee bracket. Place onto the column in the order
as shown. Make sure spacer is placed between the two steel brackets. Leave the bolt just loose
enough to allow bracket to slide freely. Note the postion of the grey brackets, the curve must go up.
Swing-Away Front
Independent Knees PNG50425
page 25 page 14
Option Assembly
Curve Up
Lateral Supports
9”-15”W
PNG50224
Slide each lateral support onto
notch and knob on the accessories
mounting bracket. Tighten knobs
securely.
To Next Page
