Eaton 600 A 15 kV class push-OP Installation, Operation And Maintenance Instructions

Rated
Volts
Rated
kVA
†Load Current Ratings (A)
Regulation Range (Wye and Open Delta)
±10% ±8.75% ±7.5% ±6.25% ±5%
Regulation Range (Closed Delta)
±15% ±13.1% ±11.3% ±9.4% ±7.5%
2500
50 200 220 240 270 320
75 300 330 360 405 480
100 400 440 480 540 640
125 500 550 600 668 668
167 668 668 668 668 668
250 1000 1000 1000 1000 1000
333 1332 1332 1332 1332 1332
416.3 1665 1665 1665 1665 1665
5000
25 50 55 60 68 80
50 100 110 120 135 160
100 200 220 240 270 320
125 250 275 300 338 400
167 334 367 401 451 534
250 500 550 600 668 668
333 668 668 668 668 668
416.3 833 833 833 833 833
7620*
38.1 50 55 60 68 80
57.2 75 83 90 101 120
76.2 100 110 120 135 160
114.3 150 165 180 203 240
167 219 241 263 296 350
250 328 361 394 443 525
333 438 482 526 591 668
416.3 548 603 658 668 668
500 656 668 668 668 668
667 875 875 875 875 875
833 1093 1093 1093 1093 1093
13800
69 50 55 60 68 80
138 100 110 120 135 160
207 150 165 180 203 240
276 200 220 240 270 320
414 300 330 360 405 480
500 362 398 434 489 579
552 400 440 480 540 640
667 483 531 580 652 668
833 604 664 68 668 668
14400
72 50 55 60 68 80
144 100 110 120 135 160
288 200 220 240 270 320
333 231 254 277 312 370
416 289 318 347 390 462
432 300 330 360 405 480
500 347 382 416 468 555
576 400 440 480 540 640
667 463 509 556 625 668
720 500 550 600 668 668
833 578 636 668 668 668
19920
100 50.2 55 60 68 80
200 100.4 110 120 135 160
333 167 184 200 225 267
400 200.8 220 240 270 320
500 250 275 300 338 400
667 335 369 402 452 536
833 418 460 502 564 668
1000 502 552 602 668 668
Rated
Volts
Rated
kVA
†Load Current Ratings (A)
Regulation Range (Wye and Open Delta)
±10% ±8.75% ±7.5% ±6.25% ±5%
Regulation Range (Closed Delta)
±15% ±13.1% ±11.3% ±9.4% ±7.5%
34500
172.5 50 55 60 68 80
345 100 110 120 135 160
517 150 165 180 203 240
690 200 220 240 270 320
Rated
Volts
Rated
kVA
†
Load Current Ratings (A)
Regulation Range (Wye and Open Delta)
±10% ±8.75% ±7.5% ±6.25% ±5%
Regulation Range (Closed Delta)
±15% ±13.1% ±11.3% ±9.4% ±7.5%
6600
33 50 55 60 68 80
66 100 110 120 135 160
99 150 165 180 203 240
132 200 220 240 270 320
198 300 330 360 405 480
264 400 440 480 540 640
330 500 550 600 668 668
396 600 660 668 668 668
11000
55 50 55 60 68 80
110 100 110 120 135 160
165 150 165 180 203 240
220 200 220 240 270 320
330 300 330 360 405 480
440 400 440 480 540 640
550 500 550 600 668 668
660 600 660 668 668 668
15000
75 50 55 60 68 80
150 100 110 120 135 160
225 150 165 180 203 240
300 200 220 240 270 320
450 300 330 360 405 480
600 400 440 480 540 640
750 500 550 600 668 668
22000
110 50 55 60 68 80
220 100 110 120 135 160
330 150 165 180 203 240
440 200 220 240 270 320
660 300 330 360 405 480
880 400 440 480 540 640
33000
165 50 55 60 68 80
330 100 110 120 135 160
495 150 165 180 203 240
333 231 254 277 312 370
660 200 220 240 270 320
TABLE 10-3. ADD-AMP Capabilities of 60 Hz Ratings
†
55/65 °C rise rating on VR-32 regulators gives an additional 12%
increase in capacity if the tap-changer’s maximum current rating
has not been exceeded. For loading in excess of the above values,
please refer to your Eaton representative.
* Regulators are capable of carrying current corresponding to rated
kVA when operated at 7200 V.
†
55/65 °C rise rating on VR-32 regulators gives an additional 12%
increase in capacity if the tap-changer’s maximum current rating has
not been exceeded. For loading in excess of the above values, please
refer to your Eaton representative.
TABLE 10-4. ADD-AMP Capabilities of 50 Hz
Ratings
110
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
