TABLE 5-2. Function Menu (continued)
Level 1 Main Menu Level 2 Sub-Menu Parameter Code
*Features, cont. *Voltage Reduction, cont. Remote #2 Value 074
Remote #3 Value 075
# of Pulse Reduction Steps 076
% of Voltage Red Per Pulse Step 077
*Tap to Neutral Tap to Neutral 170
* Soft ADD-AMP™ Soft ADD-AMP Limits 079
Soft ADD-AMP High Limits Soft ADD-AMP Low Limits 176
*Alternate Config Alternate Configuration 450
Alternate Configuration 451
*Leader/Follower LoopShare Communications 400
LoopShare Comms State 401
LoopShare Comms Port 402
LoopShare Comms Table Assignment 403
LoopShare Comms Tx Delay 404
LoopShare Comms Timeout 405
Leader/Follower 410
Leader/Follower State 411
Leader/Follower Designation 413
Follower Devices Configured 414
Leader/Follower Tap Wait Timer 415
Leader/Follower Timeout 416
Leader/Follower Retry Delay 417
Leader/Follower Retries 418
Leader/Follower Monitor 420
*Communications Com Port #1 Protocol 060
a
Com Port #1 Speed 061
a
Com Port #1 Sync Time 062
a
Com Port #1 DNP Master Adrs 063
a
Com Port #1 DNP Remote Adrs1 064
a
Com Port #1 DNP Remote Adrs2 064
a
Com Port #1 2179 Remote Adrs 064
a
Com Port #1 Handshake Mode 065
a
Com Port #1 Tx Enable Delay 066
a
Com Port #1 Tx Disable Delay 067
a
Com Port #1 2179 Ordinal Map 266
Com Port #1 DNP Data Dict 267
Com Port #2 Protocol 160
Com Port #2 Speed 161
Com Port #2 Sync Time 162
Com Port #2 DNP Master Adrs 163
Com Port #2 DNP Remote Adrs1 164
a
Settings for Com Port #1 also apply to Com Port #3.
31
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
