If there are no unacknowledged active alarms available, the
LCD displays the following message:
If there are no acknowledged active alarms available, the LCD
displays the following message:
An actual alarm display example follows:
Status alarms
The status alarms include the following:
•
Supervisory Active
•
Reverse Power Flow
•
No Input Voltage Detected
•
No Output Voltage Detected
•
Tap At Neutral
•
PMT Mode A in Progress
•
PMT Mode B in Progress
•
Volt Limit On
•
Reg Blocked Annunciator
•
Voltage Reduct On Annunciator
•
Alternate Profile Active
•
Default Time
•
Power Up Self Test Error
•
Met Indeterminate Pwr Dir
•
Met Rev Pwr Flow
•
LF Ldr Unable to Operate
•
LF Ldr Inactive
•
LF Follower Not Ready
•
LS Loss of Comms
•
Motor Trouble
Data alarms
Instantaneous metering quantities
For most Instantaneous Metering quantities, there are two
data alarms available: One that can be triggered for a HIGH
threshold value and one that can be triggered for a LOW
threshold value.
•
Secondary Load Voltage High
•
Secondary Load Voltage Low
•
Secondary Source Voltage High
•
Secondary Source Voltage Low
•
Compensated Voltage High
•
Compensated Voltage Low
•
Primary Load Voltage High
•
Primary Load Voltage Low
•
Primary Source Voltage High
•
Primary Source Voltage Low
•
Load Current High
•
Load Current Low
•
Power Factor Low (only LOW threshold is available)
•
kVA High
•
kVA Low
•
kW High
•
kW Low
•
KVAR High
•
KVAR Low
•
Forward kWHr High
•
Forward kWHr Low
•
Reverse kWHr High
•
Reverse kWHr Low
•
Forward KVARHr High
•
Forward KVARHr Low
•
Reverse KVARHr High
•
Reverse KVARHr Low
•
Frequency High
•
Frequency Low
•
Load Voltage Total Harmonic Dist. High (only HIGH
threshold is available)
•
Load Current Total Harmonic Dist. Low (only LOW
threshold is available)
No Unacknowledged
Active Alarms
No Acknowledged
Active Alarms
System Alarm #1 is
Active
01/14/2004 11:35:58a
(MORE...□)
72
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
