SPEAR™ Single-Phase Recloser System
INSTALLATION AND OPERATION INSTRUCTIONS MN280048EN June 2016
Figure 21.
Heater 2 Heater 1
045 047
048 046
FU1
013
012
012 013
120/240 VAC
CUSTOMER CONTROL
POWER INPUT R2
BLK WHT*
B A
CUSTOMER
WIRING
120/240 VAC CUSTOMER CONTROL POWER INPUT
NEUTRAL* HOT
TO R1-J
015
015
OPTIONAL FACTORY
ACCESSORY WIRING
* Neutral must be connected to Earth ground, external to the control, in order to ensure accurate voltage reading
120 or 240 VAC 2-wire control power input (shown with default factory wiring connected to single-phase
voltage input supply)
